Modified PP
Classification:
Product Introduction
Product Details
Modified PP
| Modified PP | ||
| Mineral-filled PP | ||
| 1 | Black PP-TD10 | P6M10B02 |
| 2 | Purple PP-TD20 | P6M20V06 |
| 3 | Yellow PP-TD20 | P6M20Y09 |
| 4 | Black PP-TD30 | P6M30B01 |
| 5 | Natural PP-TD40 | P6M40NC01 |
| Glass fiber reinforced PP | ||
| 1 | Black PP-GF20 | P6G20B01 |
| 2 | Natural PP-GF30 | P6G30NC04 |
| 3 | Natural PP-GF40 | P6G40NC01 |
| Flame retardant PP | ||
| 1 | Black V2 flame retardant PP | P5NHB02 |
| 2 | Natural V0 flame retardant PP | P6NH01 |
| Filled flame retardant PP | ||
| 1 | Gray PP-TD20V2 flame retardant | P6M20NHGY33 |
| Reinforced flame retardant PP | ||
| 1 | Natural PP-GF10 V0 flame retardant | P6G10NHNC01 |
| 2 | Orange PP-GF20 V0 flame retardant | P6G20NHO01 |
| 3 | Orange PP-GF30 V0 flame retardant | P6G30NHO13 |
Mineral-filled PP
Product introduction: Mineral-filled modified PP, mainly used in automobiles, electric vehicles, and home appliances, and widely used in industrial, packaging, and furniture fields (especially in cost-sensitive areas requiring good structural performance).
Product details: Mineral-filled PP, injection molding grade. Using talc and calcium carbonate as fillers, the product has high modulus and high impact resistance, good dimensional stability, good heat resistance, and good molding processability.
| Main performance items | Unit | Test standard | Black PP-TD10 P6M10B02 |
Purple PP-TD20 P6M20V06 |
Yellow PP-TD20 P6M20Y09 |
Black PP-TD30 P6M30B01 |
Natural PP-TD40 P6M40NC01 |
| Density | g/cm3 | ISO 1183 | 0.954 | 1.061 | 1.085 | 1.14 | 1.229 |
| Ash | % | ISO 3451 | 6 | 22 | 24 | 30 | 37 |
| Tensile strength | MPa | ISO 527 | 24 | 21 | 21 | 21 | 17 |
| Elongation at break | % | ISO 527 | 495 | 177 | 169 | 29 | 353 |
| Flexural strength | MPa | ISO 178 | 26 | 31 | 33 | 32 | 30 |
| Flexural modulus | MPa | ISO 178 | 920 | 1845 | 1851 | 1909 | 1734 |
| Notched Izod impact strength (23℃) | KJ/m2 | ISO 180 | 68.2（H） | 19.8 | 12 | 13.2 | 11.5 |
| Notched Izod impact strength (-40℃) | KJ/m2 | ISO 180 | 10.5 | 6.3 | 6.3 | 6.2 | 5.9 |
| Unnotched Izod impact strength (23℃) | KJ/m2 | ISO 179 | N | N | N | N | N |
| Unnotched Izod impact strength (-40℃) | KJ/m2 | ISO 179 | 120.2 | 63 | 36.6 | 32 | 56 |
| Melt flow index (230℃/2.16kg) | g/10min | ISO 1133 | 3.4 | 19.2 | 18.8 | 21.5 | 15.2 |
Glass fiber reinforced PP
Product introduction: Glass fiber reinforced modified PP, mainly used in the automotive industry, home appliance field, industry and construction, communication engineering, and power tools.
Product details: Glass fiber reinforced PP, reinforced grade, injection molding grade. The product has high strength and high modulus, good dimensional stability, good heat resistance, and good molding processability.
| Main performance items | Unit | Test standard | Black PP-GF20 P6G20B01 |
Natural PP-GF30 P6G30NC04 |
Natural PP-GF40 P6G40NC01 |
| Density | g/cm3 | ISO 1183 | 1.094 | 1.118 | 1.21 |
| Ash | % | ISO 3451 | 25 | 30 | 40 |
| Tensile strength | MPa | ISO 527 | 48 | 69 | 78 |
| Elongation at break | % | ISO 527 | 13 | 7 | 6 |
| Flexural strength | MPa | ISO 178 | 64 | 103 | 117 |
| Flexural modulus | MPa | ISO 178 | 3163 | 8600 | 7157 |
| Notched Izod impact strength (23℃) | KJ/m2 | ISO 180 | 13.3 | 32.3 | 25.8 |
| Notched Izod impact strength (-40℃) | KJ/m2 | ISO 180 | 8.6 | 18.2 | 17.5 |
| Unnotched Izod impact strength (23℃) | KJ/m2 | ISO 179 | 34 | 89 | 78 |
| Unnotched Izod impact strength (-40℃) | KJ/m2 | ISO 179 | 33 | 84 | 72 |
| Melt flow index (230℃/2.16kg) | g/10min | ISO 1133 | 10.4 | 5.6 | 8.8 |
Flame retardant PP
Product introduction: Flame retardant modified PP, mainly used in animal husbandry, electronics and electrical appliances, automotive industry, medical devices, machinery parts, and household appliance shells.
Product details: Flame retardant PP, phosphorus-nitrogen system, injection molding grade. The product has excellent flame retardancy and high fluidity, and good molding processability.
| Main performance items | Unit | Test standard | Black V2 flame retardant PP P5NHB02 |
Natural V0 flame retardant PP P6NH01 |
| Density | g/cm3 | ISO 1183 | 0.93 | 1.029 |
| Ash | % | ISO 3451 | / | / |
| Tensile strength | MPa | ISO 527 | 32 | 18 |
| Elongation at break | % | ISO 527 | 74 | 362 |
| Flexural strength | MPa | ISO 178 | 38 | 27 |
| Flexural modulus | MPa | ISO 178 | 1374 | 1192 |
| Notched Izod impact strength (23℃) | KJ/m2 | ISO 180 | 11.5 | 23.1 |
| Notched Izod impact strength (-40℃) | KJ/m2 | ISO 180 | 5.8 | 5.6 |
| Unnotched Izod impact strength (23℃) | KJ/m2 | ISO 179 | 190（H） | N |
| Unnotched Izod impact strength (-40℃) | KJ/m2 | ISO 179 | 25 | 36 |
| Melt flow index (230℃/2.16kg) | g/10min | ISO 1133 | 4 | 2.3 |
| Flame retardant performance | 1.6mm | UL94 | - | V-0 |
| 2.0mm | V-2 | V-0 |
Filled flame retardant PP
Product introduction: Mineral-filled flame retardant modified PP, mainly used in cable engineering, new energy vehicle industry, home appliances and electronics, and industrial construction.
Product details: Mineral-filled flame retardant PP, phosphorus-nitrogen system, injection molding grade. Using talc as a filler, the product has excellent flame retardancy, high modulus, and high strength, good dimensional stability, and good molding processability.
| Main performance items | Unit | Test standard | Gray PP-TD20 V2 flame retardant P6M20NHGY33 |
| Density | g/cm3 | ISO 1183 | 1.065 |
| Ash | % | ISO 3451 | 22 |
| Tensile strength | MPa | ISO 527 | 20 |
| Elongation at break | % | ISO 527 | 266 |
| Flexural strength | MPa | ISO 178 | 30 |
| Flexural modulus | MPa | ISO 178 | 1456 |
| Notched Izod impact strength (23℃) | KJ/m2 | ISO 180 | 9.7 |
| Notched Izod impact strength (-40℃) | KJ/m2 | ISO 180 | 5.6 |
| Unnotched Izod impact strength (23℃) | KJ/m2 | ISO 179 | N |
| Unnotched Izod impact strength (-40℃) | KJ/m2 | ISO 179 | 42 |
| Melt flow index (230℃/2.16kg) | g/10min | ISO 1133 | 13.4 |
| Flame retardant performance | 1.6mm | UL94 | V-2 |
| 3.2mm | V-2 |
Reinforced flame retardant PP
Product introduction: Glass fiber reinforced modified flame retardant PP, this type of product is mainly used in new energy vehicles, traditional vehicles, electronic appliances, household appliances, industrial equipment, and construction.
Product details: Glass fiber reinforced flame retardant PP, phosphorus-nitrogen system, injection molding grade. Using short cut glass fiber as a filler, the product has excellent flame retardancy, high modulus, and high strength, good dimensional stability, good heat resistance, and good molding processability.
| Main performance items | Unit | Test standard | Natural PP-GF10 V0 flame retardant P6G10NHNC01 |
Orange PP-GF20 V0 flame retardant P6G20NHO01 |
Orange PP-GF30 V0 flame retardant P6G30NHO13 |
| Density | g/cm3 | ISO 1183 | 1.082 | 1.194 | 1.32 |
| Ash | % | ISO 3451 | 11 | 30 | 39 |
| Tensile strength | MPa | ISO 527 | 35 | 58 | 52 |
| Elongation at break | % | ISO 527 | 6 | 5 | 6 |
| Flexural strength | MPa | ISO 178 | 56 | 73 | 87 |
| Flexural modulus | MPa | ISO 178 | 2706 | 4138 | 6919 |
| Notched Izod impact strength (23℃) | KJ/m2 | ISO 180 | 6.2 | 16.6 | 12.2 |
| Notched Izod impact strength (-40℃) | KJ/m2 | ISO 180 | 4.8 | 9.3 | 7.7 |
| Unnotched Izod impact strength (23℃) | KJ/m2 | ISO 179 | 32 | 35 | 33 |
| Unnotched Izod impact strength (-40℃) | KJ/m2 | ISO 179 | 21 | 29 | 28 |
| Melt flow index (230℃/2.16kg) | g/10min | ISO 1133 | 5.9 | 7 | 6.9 |
| Flame retardant performance | 1.6mm | UL94 | V-0 | V-0 | V-0 |
| 3.2mm | V-0 | V-0 | V-0 |
